Hydraulic valves motor control valve
Home > Produkt-Liste > Hydraulikkolbenmotor A2F > Hydraulic valves motor control valve

Hydraulic valves motor control valve


  • Hydraulic valves motor control valve

Hydraulic valves motor control valve

    Zahlungsart: T/T
    Terms of Trade: FOB,CFR,CIF
    Minimum der Bestellmenge: 5 Ton
    Lieferzeit: 30 Tage
    Verpakung: Export standard packing
    Produktivität: 500tons per month
    Marke: A&M
    Transport: Ocean,Land,Air
    Ort Von Zukunft: CHINA
    Versorgungsmaterial-Fähigkeit: 500tons per month
    Zertifikate : ISO SGS
    HS-Code: 8431390000
    Hafen: Tianjin

Produktbeschreibung

Product Description

The motor control valve is equipped with high performance motor products, mainly used in A2F and A6V series motor products.

Balance valves for walking drive/hoisting are designed to reduce the risk of overspeed and cavitation of the axial piston motor in the open circuit. If the inlet pressure is reduced, the balance valve spool will throttle the return flow of oil and brake the motor until the inlet pressure returns to about 2 MPa.

TECHNICAL FEATURE

01.Symmetrical design, precise valve opening to ensure consistent positive and negative performance 02.High strength and high elongation cast iron valve body, meeting the peak pressure of 45MPa

SPECIFICATION
Working pressure
Peak pressure
Maximum flow rate
Brake spool opening pressure
Brake spool end
opening pressure
Pressure relief valve for brake release
Open pressure
35MPa
42MPa
220L/min
2MPa
4MPa
2.1+0.4MPa
1+0.4MPa
Detailed Images
Company Introduction
The company integrates research and development and manufacturing of high-end hydraulic product, and is one of the largest and competitive manufacturing enterprises for high-end hydraulic products in China. The company is recognized “high-tech enterprise”by the state. It has an enterprise technology center certified by the state. The annual production capacity reaches 3 million hydraulic components, 40,000 sets hydraulic systems and 20,000 tons of hydraulic castings. The products are widely used in construction machinery, iron and steel, metallurgy, hydraulics, environmental protection, offshore engineering, high-speed rail, wind power, new energy, etc., and have completed a number of national key projects, the products are exported to Europe, America, Asia and Africa. The company continues to strengthen the innovation drive, products and technology continue to expand to high-end manufacturing.

The company consists of four branches: Hydraulic Pump Branch, Hydraulic Valve Branch, Hydraulic System Branch and Casting Branch, there are three subsidiaries of R&D and manufacturing in Taiyuan, Changzhi, Jinan and Shanghai. They produces 3 million units of hydraulic components, 40 thousand sets of hydraulic system equipment, 35 thousand tons of hydraulic castings annually, including high-pressure piston pump, vane pump,gear pump, hydraulic valve, motor, hydraulic cylinder, hydraulic system and castings. They mainly used in engineering machinery, agricultural machinery, transportation (locomotives, rail transit, ships), petroleum machinery, metallurgical steel, coal mines, marine engineering, aerospace, water conservancy and power, machine tool industry, chemical equipment and other fields. The company has provided products for national key projects such as the Three Gorges Project, the South-to-North Water Transfer Project, the localization of metallurgical slab continuous casting and rolling production line and so on.
Product packaging
Our Advantages
The company is a state-recognized high-tech enterprise, with state-recognized hydraulic industry enterprise technology center,and has established a post-doctoral research station with strong independent technology research and product development capabilities. The company has 239 outstanding professionals in development and basic technology, process innovation research of product , including more than 60 senior technical titles. The technology center has established an open operation mode, paying attention to the organic combination of production, education and research, and has established exchanges and cooperation relations with more than 20 universities, colleges and institutes, such as Tinghua University, Beijing Aerospace University, Taiyuan University of Technology, Beijing Institute of Automation, Tianjin Institute of Construction Machinery, etc., and continue to maintain leadership in designing of high-end hydraulic product and controlling of hydraulic-electro-mechanical and other technical fields. The company participated in formulating 21 national and industrial product standards, and obtained 24 invention and practical patents, and won 66 technology progress awards and outstanding new product awards.
Why Choose Us
The company has established a complete quality management system, with the certification of informatization and industrialization "two-oriented integrated management system", and comprehensively implemented refined management to constantly improve product quality and economic benefits.

The company has established a nationwide marketing and service network, dedicated to providing customers with perfect services. We have actively promoted the internationalization strategy and established strategic partners and service agencies in Europe, the Americas, Asia and Africa.

The company upholds the core values of "integrity, innovation, leanness, excellence" and takes the revitalization of China's hydraulic industry as its responsibility to vigorously promote independent innovation and help the development of high-end equipment manufacturing industry.
A&M Manufacturing Co.Ltd.



A & M Company ist ein chinesisch-britisches Joint Venture mit Hauptsitz in Großbritannien und mehr als 30 Jahren Erfahrung in der Gießereiindustrie und der allgemeinen Metallverarbeitung. Seit mehr als 20 Jahren kooperiert und investiert das Unternehmen Gießerei in China. Es ist eine professionelle Gießerei, die Entwicklung und Produktion integriert und sich auf die Herstellung verschiedener Sand- und Präzisionsgussteile aus Eisen / Stahl, Hydraulikventilen, Hydraulikpumpen, Hydraulikmotoren, Hydraulikzylindern und Hydrauliksystemen spezialisiert hat. Diese Gussteile werden häufig in der Automobilindustrie, in Schienenfahrzeugen, Baumaschinen, im Kommunalbau, in Rohrleitungen, in der Petrochemie, im Bergbau, in der Energiewirtschaft und in anderen Branchen eingesetzt.

Derzeit produziert es jährlich 2 Millionen Stück Ersatzteile, einschließlich Autoersatzteile für alle Arten von Fahrzeugen, mechanische Ersatzteile und Ersatzteile für Schienenfahrzeuge mit einer jährlichen Produktionskapazität von 1 Milliarde Yuan.

Unser Unternehmen hat die Zertifizierung nach ISO9001: 2008.ISO / TS16949: 2009.ISO14001: 2008 und OHSAS18001: 2007 erfolgreich bestanden und das TPG-Zertifikat vom Drittanbieter von GE erhalten.

Wir verfügen über 7 Sätze halbautomatischer Formanlagen, 164 Sätze CNC-Maschinen und Bearbeitungszentren, einen Spektrumanalysator für Deutschland, Röntgenprüfgeräte, 56 Sätze Inspektionsgeräte und 11 Sätze Reinigungsgeräte.
